Atrix
LV 5–120kWh · IP20
Reliable power. Built to grow.
A flexible indoor energy-storage system designed for dependable everyday performance, easy installation and scalable capacity.
Get the Highlights
5kWh
Usable energy
Usable energy
100% DOD
Scalable to
120kWh
120kWh
Expand as your
needs grow
needs grow
~16 Years
Daily Cycling
Daily Cycling
6,000 life cycles
1C Charge &
Discharge
Discharge
Strong energy
delivery
delivery
Built-in
Heater
Heater
Reliable low temperature operation
All 5kWh. All available.
Atrix provides 5kWh of nominal and usable energy with 100% depth of discharge, allowing you to make full use of the energy stored inside.
kWh
Start with 5.
Scale to 120.
Build your storage system one module at a time, expanding the capacity as your household or energy requirements change.
Flexible modular expansion
Wall-mounted or rack-mounted setup
Built-in flexible battery rack
Power that performs
Everyday Power
Reliable performance for normal daily use.
50A Rated
Higher Demand
Extra power when your energy needs increase.
100A Maximum
Less Energy Lost
Over 98% efficiency from charge to discharge.
>98% Roundtrip Efficiency
Built for years of everyday use.
~16
Years
of Daily Cycling
With 6,000 cycles, Atrix is designed for dependable daily use year after year.
Day 1
Ready for everyday use.
Around 8 Years*
About 3,000 daily cycles.
Around 16 Years*
Nearly 6,000 daily cycles.
Smart & Connected
Built to communicate
CAN 2.0 and RS485 allow Atrix to communicate with compatible inverters and connected energy-system components.
CAN 2.0
RS485
Compatible
Inverters
Inverters
Designed for
flexible installation.
Rack-mounted
Flexible modular configuration
Wall-mounted
Compact installation
Built-in Battery Rack
Simplifies system expansion
Quick DC Connection
Easy plug-and-unplug terminals
Dimensions (W×H×D)
482 × 135 × 433mm
Weight
45kg (per pack)
Safe. Certified. Reliable.
IEC62619
Certified
CE
Compliant
UN38.3
Certified
IP20
Designed for indoor
installation
installation
UL 1973
Certified energy-storage
safety
safety
Technical specs at a glance
Specification
Value
Nominal / Usable Energy
5kWh / 5kWh at 100% DOD
Rated Voltage
51.2V
Rated Charge/Discharge Current
50A / 50A
Max Charge/Discharge Current
100A / 100A
Roundtrip Efficiency
>98%
Public Scalability
Up to 120kWh
Communication
CAN 2.0 / RS485
Installation
Wall-mounted or rack-mounted
Dimensions per Pack
482 × 135 × 433mm
Protection Rating
IP20
7-Year Warranty
6+1 years with internet connection
Expert Support
When you need it
Quality Assured
Built to the highest standards
Ready when you are
Build the power your home needs.
Flexible capacity. Reliable performance. Atrix grows with your energy requirements.
